3DEXPERIENCE CATIA 2022x: Advanced Surface Design - Paperback

by Ascent - Center for Technical Knowledge (Author)

The 3D EXPERIENCE CATIA 2022x Advanced Surface Design learning guide expands on the knowledge learned in the 3DEXPERENCE CATIA 2022x: Introduction to Surface Design learning guide by covering advanced curve and surface topics found in the Generative Shape Design Application. Topics include advanced curve construction, advanced swept, blend and offset surface construction, complex fillet creation, and the use of laws.

Curve and surface analysis are introduced for users to validate their model's geometry. Tools and methods for rebuilding geometry are also discussed. As with the 3DEXPERENCE CATIA 2022x: Introduction to Surface Design learning guide, meeting model specifications (such as continuity settings) remains forefront in introducing tools and methodologies.

Topics Covered

• Surface Design Overview

• Advanced Wireframe Elements

• Curve Analysis and Repair

• Swept Surfaces

• Blend Surfaces

• Adaptive Sweep

• Laws

• Advanced Surface Fillets

• Alternative Filleting Methods

• Duplication Tools

• Knowledge Templates

• Surface Analysis and Repair

• Offset Surfaces

• Project Exercises


Prerequisites

• Access to the 3DEXPERIENCE CATIA 2022x version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Syst鑪es may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (e.g., 3DEXPERIENCE CATIA 2021x).

• Completion of the 3DEXPERIENCE CATIA 2022x: Introduction to Surface Design course is recommended.
