Oscillator Circuits - Paperback

by Rudolf Graf (Author)

This series of circuits provides designers with a quick source for oscillator circuits. Why waste time paging through huge encyclopedias when you can choose the topic you need and select any of the specialized circuits sorted by application?

This book in the series has 250-300 practical, ready-to-use circuit designs, with schematics and brief explanations of circuit operation. The original source for each circuit is listed in an appendix, making it easy to obtain additional information.

Back Jacket

Oscillator Circuits provides fast, easy access to more than 250 ready-to-use circuits in their original form. Circuits include: audio, burst, sine-wave, miller, colpitts, wien-bridge, multivibrators, crystal, RF, square-wave, pierce, TTL, code, voltage-controlled, and function generators. Each schematic is accompanied by a brief explanation of how the circuit works, and the original source is given in a section at the back of the book, making it easy to obtain further information.
